Description
Product Model:
HG-L203
Title:
LINEAR FIXTURE (STRIP, WRAP)
Description:
Halcon high quality LED Utility Wraps Series is a cost-effective, energy-efficient lighting solution that meets building and safety codes for high-occupancy dwellings, parking garages, stairwells and other commercial utility applications. feature field-Wattage and CCT selectable, and provides an emergency battery back up option. LED Utility Wraps consume less power than fluorescent wrap-around fixtures while delivering high efficacy.
Product Category:
LINEAR FIXTURE (STRIP, WRAP)
Size:
2ft, 4ft, 5ft, 6ft, 8ft
Watts(W):
20W, 30W, 40W, 60W, 80W, 100W
Lumen(lm):
2500 lm-10000 lm
CCT(K):
3000K/3500K/4000K/5000K
Qualifications:
DLC Standard/DLC Premium.
ETL/CETL List
Design and Installation – Feactures:
Available Switchable Color and Adjustable Lumen Technology. Faster installation and cleanup
• 0-10V dimming standard
• CRI>80
• Universal voltage 120-277V
• -4°F to 122°F (-20°C to 50°C), except fixtures with EM option
• Fixture may be surface mounted or pendant/Rod mounted
(accessories sold separately)
Design and Installation – Controls Features:
- Daylight Sensor
• Occupancy Sensor
• Integral Sensor Receptacle
• High-end Trim
• Bluetooth
Design and Installation – Accessories:
SENSOR control, Emergency kits, suspension kits.
Specification – Size:
588x182x102mm, 1188x182x102mm, 1188x182x102mm, 1488x182x102mm, 1488x182x102mm, 1788x182x102mm, 2488x182x102mm
Specification – Nominal Wattage:
20W, 30W, 40W 40W, 60W, 80W, 100W
Specification – InputVoltage:
AC 120-277V, 120-347V
Specification – Lumen Delivered:
2400 lm, 3600 lm, 4800 lm, 4800 lm, 7200 lm, 9600 lm, 12000 lm
Specification – Nominal Efficacy:
120 lm/w
Specification – CCT:
3000K/3500K/4000K/5000K
Specification – CRI:
>80
Specification – Power Factor:
>0.9
Specification – Dimming:
0-10V
Specification – Operating Temperature:
: -4˚F to 122˚F (-20˚ C to 50˚C ), except EM models. For EM model: 50˚F to 104˚F (10˚C to 40˚C )
Specification – Warranty:
5 Years
Specification Products:
HG-L203-20W/2ft, HG-L203-30W/4ft, HG-L203-40W/5ft, HG-L203-60W/5ft, HG-L203-80W/6ft, HG-L203-100W/8ft
